Shenzhen Hejia Automatic Printing Machine Co., Ltd. is one of the leading manufacturers and suppliers of automatic screen printing equipment in China, featured by quality products and good prices. Please rest assured to buy advanced automatic screen printing equipment for sale here from our factory.
Description
The automatic screen printing equipment is designed to decorate round and oval bottles, jars, tubes in multi colors. It prints by using UV ink or LED ink with strong adhesion, driven by servo motor. There is no requirement for a registration point on the bottles.
Application
Plastic/glass/metal cylindrical bottles, jars and tubes can be automatically printed by this machine. Can be flexibly combined and matched according to different needs, realize screen printing and hot stamping in one process.
Features
1. Automatic feeding and unloading system with multi axis servo robot.
2. Pre-heating with flame treatment and pre-cleaning with anti-static dust cleaning system (optional).
3. All servo driven screen printing/hot stamping.
4. Automatic curing by UV or LED after each color is printed.
5. Taiwan Dex Indexing table system with optimum precision.
6. Safety design, the automatic screen printing equipment house with CE standard.
7. PLC control, all parameters set by touch screen.
Tech - data
| Max printing diameter | 70mm |
| Max printing length | 150mm |
| Max printing speed | 30 - 50 pcs/min |
| UV power (UV/LED) | 4000watts/720w |
